Mesquite Rocker Scientist
4 Day Seminar
After introductions and a tour of the shop, the plans packet is handed out, along
with a list of the tools and supplies I use to make a rocking chair. Everything used in the assembly of this chair
is readily available, and all sources are given for each item.
The rocking chair seat boards are laid out and marked, then band sawn into rough shape. The front and back leg
joints are cut and routed. At the end of the day the seat blank is epoxied together, and left to cure overnight.
The front legs are notched, routed, band sawn, and fit into the seat blank, then shaped.
The back leg joints are notched at an angle using a special router jig to form an outward splay.
The clamps are removed from the seat blank, and it is sculpted into shape using
a combination of carbide grinding wheels, die grinders, and various sanders. The outer edge is cut to shape
and routed with a round-over.
The back legs are sculpted into shape using a band saw, router, grinding wheel and sanding equipment.
The front and rear legs are dry-clamped into place, and the arms are now fit and shaped using the band saw and
carbide grinding wheel. A blind-doweling technique is used to attach the arms to the front and back legs. No
screws are used in this chair.
The whole assembly is now epoxied in place, using a special alignment jig to check the outward splay of the back
legs. The front legs and arms are also epoxied and clamped on the chair.
The clamps are removed from the chair assembly, and all of the joints are shaped
and faired-in with various electric and air tools. The holes are drilled in the seat for the back slats.
The headcrest is fitted to the chair by cutting end angles on the table saw, then the blank is band sawed into
rough shape, and the back slat holes drilled.
Back slats are now band sawn into shape, marked, and sculpted into final shape. The ends are fit into the
seat and the headcrest.
The rockers are band sawn to shape, and attached to the bottom of the front and rear legs. A special doweling procedure
is used in this process.
The back slats, headcrest, and rockers are now all epoxied onto the rocking chair assembly, and clamped for an
Clamps are removed, and the rockers are shaped into the front and back legs. The
headcrest is brought into final shape using the carbide grinding wheel, along with assorted die grinders and finish
The rocking chair is now at a point where it can be "test driven" by Robert and the class.
For the rest of the morning, finishing methods and techniques are shown and discussed. The chair is sprayed
with a lacquer to demonstrate the technique, plus show the color of the finished wood.
The class usually concludes by noon after a class photo session.
Woodworking is inherently dangerous.
All participants are required to sign a liability release form before each seminar commences.
